Segregation mechanisms of tissue cells: from experimental data to models
© Mehes and Vicsek; licensee Springer. 2013
Received: 30 November 2012
Accepted: 28 January 2013
Published: 13 March 2013
Considerable advance has been made in recent years in the research field of pattern formation by segregation of tissue cells. Research has become more quantitative partly due to more in-depth analysis of experimental data and the emergence modeling approaches. In this review we present experimental observations, including some of our new results, on various aspects of two and three dimensional segregation events and then summarize the computational modeling approaches.
KeywordsSegregation Cell Culture Sorting Motility Differential adhesion Development Model Simulation
Pattern formation by concerted motion of large populations of different cell types is a ubiquitous phenomenon in several biological events, such as embryonic development of various species as well as tumor formation and even with some impact in tissue engineering. Patterns can form as a response by cells to external guidance cues such as morphogens or chemotactic substances or as a process where instead of external cues the local cell-cell interactions and the inherent mechanical or motility characteristics of the cell types will give rise to various multicellular patterns through physical segregation (or sorting) of these cell types. In this review we collect a naturally incomplete list of experimental observations on various aspects of 2- and 3-dimensional segregation events, and then summarize, where available, some computational models on segregation and compare them with experimental findings.
Experimental data on segregation
Two-dimensional segregation: pattern formation on a substrate
Basic drives and mechanisms of pattern formation events taking place e.g. during embryonic development can be studied in simplified experimental systems where complexity is reduced and the events are more accessible for quantitative analysis.
Additional file 1:mov. 2-dimensional segregation of mixed tissue cells. Segregation in a mixed co-culture of primary goldfish keratocytes (PFK, red) and EPC fish keratocytes (EPC, green) migrating on tissue culture plastic surface is imaged by time-lapse videomicroscopy. Fluorescent cell labels: red: cell tracker CMPTX, green: cell tracker CMFDA. Videomicroscopy duration: 20 hours, images were acquired every 10 minutes by a Zeiss Axio Observer system. (MOV 16 MB)
Segregation events in three dimensions: gastrulation and tissue organization
Three-dimensional segregation of cell populations is most prominent during gastrulation, the early phase of embryonic development resulting in the formation of main germ layers that later on give rise to all tissues. Gastrulation is a spectacular event under the microscope involving collective motion of large number of cells, but although gastrulation events have been known since early embryonic works at the beginning of the 20th century, the basic mechanisms that provide for both its accuracy and robustness are just being uncovered. Segregation of cell populations adopting different cell fates into distinct domains is governed by their mechanical properties and active motion, and constitutes an important driving mechanism of gastrulation and tissue organization. Segregation is also important in other embryonic processes, such as blastocyst formation in mammals or the development of the initial blood vessel network in birds, where precursor cells differentiate in a spatially random pattern and they have to find their way to join and form an organ.
Cell segregation was first demonstrated by the experiments of Townes and Holtfreter in which presumptive neural and epidermal cells were isolated from amphibian gastrulas, subsequently they were mixed and they autonomously sorted into separate tissues (Townes & Holtfreter 1955). In similar early experiments, mixed cells isolated from the adult Hydra were shown to segregate and form separate tissues (Gierer et al. 1972).
Segregation of various cell types in 3-dimensions was studied is several works (Foty et al. 1996; Beysens et al. 2000; Foty & Steinberg 2005; Krieg et al. 2008; Schötz et al. 2008), aiming to explain the observed configurations of segregated domains, typically the envelopment of one cell type by the other, evolving from an initial mixture of cells. These in vitro segregating systems are considered to be analogous to non-mixing liquids and their segregation is shown to be driven by differences in tissue surface tension (TST) of the constituent cell types (Foty et al. 1996). Several works tested the contribution of cell-cell adhesion (Foty & 2005; Schötz et al. 2008) and cell cortex tension (Krieg et al. Steinberg 2008; Maître & Heisenberg 2011) to TST. The developmental aspects of cell sorting and TST are detailed in a recent review by Krens and Heisenberg (2011).
Experimental proof on the relative weights of adhesion and cell cortex tension in controlling cell-cell contact formation in zebrafish germ layer progenitors and determining the experimentally measurable separation force between cell pairs was provided by Maître et al. (2012). Cells are described as fluid objects with viscoelastic cortex under tension and adhesive bonds maintaining cell-cell contacts. Contact expansion is controlled by cell cortex tension at the contact, generated by myosin-2 activity, while adhesion by cadherins (membrane-spanning adhesion molecules) mechanically couples the adhering cells, and such coupling is limited by cadherin anchorage to the sub-membrane cortex. Cell segregation is mainly driven by contact formation by the active reduction of cell cortex tension at cell-cell interface, which leads to decrease in cell-cell interface tension, while cell cortex tension at the cell-medium interface is maintained, accounting for maintained TST. Adhesion is shown to have little direct function in contact expansion. Considering the typical cadherin density, the adhesion energy per unit area of the cell surface (~1 × 10-7 N/m) is several orders of magnitude lower than typical TST measured in cell aggregates (being in the order of 1 × 10-3 N/m) (Amack & Manning 2012).
Two opposing hypotheses have been developed for explaining the origin of tissue surface tension. One is the differential adhesion hypothesis (DAH), developed by M. Steinberg (1962a); (1962b); Steinberg 1963; Steinberg 1996) postulating that tissue surface tension is proportional to the intensity of adhesive energy between point object cells. This hypothesis was elaborated in extensive modeling approaches by J. Glazier (1992). Experimental studies showed that TST is proportional to cadherin levels (Foty & Steinberg 2005).
The other hypothesis is the differential interfacial tension hypothesis (DITH), developed by Harris (1976), Brodland (2002; Brodland 2003) and Graner (1993), postulating that tissue surface tension arises from cortical tension of individual cells generated by actomyosin contractility, while a cell’s mechanical energy changes with cell shape. This model was also supported by experimental data on cell cortex tension and TST (Krieg et al. 2008).
A model integrating cell-cell adhesion and contractility of cell interfaces in the generation of tissue surface tension, the driving force of cell segregation and tissue spreading, was provided by Manning et al. (2010). This model specifies an explicit relationship between surface tension and the ratio of effective adhesion (γ) to cortical tension (β). Effective adhesion, γ, is the net energetic contribution of contacting cell surfaces, which depends on the free energy of cadherin bonds and local changes in cell cortex tension. Surface tension exhibits a crossover at γ/β ~ 2 from adhesion-dominated behavior (DAH) in the regime of γ/β < 2 to a dependence on cortical tension and other mechanical effects in the regime of γ/β > 2.
A recent review emphasizes the role of boundary cells in TST as they can actively change their mechanical properties generating different cortical tensions along their internal and external interfaces. Such ‘mechanical polarization’ is suggested to exert the same net mechanical effect on the tissue as if extra adhesion was introduced among all cells and it is hypothesized to dominate TST instead of the mechanical energy of adhesive bonds (Amack & Manning 2012). Strong apical-basal actin polarization was indeed shown in surface cells in zebrafish embryonic explants (Krens et al. 2011). Considering the low adhesion energy of cadherins, the findings that TST is proportional to the number of surface cadherins (Foty & Steinberg 2005) can also be interpreted in a way that it is signaling through more cadherins leading to increased actomyosin contractility and resultant cell cortex tension which generates higher TST.
In a study quantifying the adhesive and mechanical properties of zebrafish germ line progenitor cell types Krieg et al. (2008) investigated the role of tensile forces in cell segregation. Using single-cell force spectroscopy they have measured the cell-cortex tension of these cell types (ectoderm, mesoderm and endoderm) while specifically interfering with actomyosin-dependent cell-cortex tension. Performing segregation experiments using cell types with altered myosin activity they have demonstrated that differential actomyosin-dependent cell-cortex tension is required and sufficient to direct the segregation of cell types and determine the final configuration of the segregated domains.
Additional file 2:mov. 3-dimensional segregation of mixed tissue cells. Segregation in a mixed co-culture of primary goldfish keratocytes (PFK, red) and EPC fish keratocytes (EPC, green) suspended in agarose micromold is imaged by time-lapse videomicroscopy. Fluorescent cell labels: red: cell tracker CMPTX, green: cell tracker CMFDA. Videomicroscopy duration: 20 hours, images were acquired every 10 minutes by a Zeiss Axio Observer system. (MOV 5 MB)
In early embryonic development, during the blastocyst formation in mice, cell fate specification of epiblast and primitive endoderm cells occurs in a spatially mixed way, followed by their active segregation into distinct domains (Morris et al. 2010). Experimental studies of this process have revealed that segregation cannot be attributed to differential adhesion only but other processes such as active motion and apical-basolateral polarization of surface endoderm cells eventually surrounding the epiblast cells appear to contribute to it (Moore et al. 2009). It is also proposed and that repositioning of cells in turn influences their fate.
Pattern formation by segregation is a process that is not confined to embryonic development. In a recent publication Inaba et al. (2012) studied the formation of skin pigment patterns in the adult zebrafish. They have demonstrated that segregation of the two pigment cell types eventually forming the stripe pattern is governed by their short-range repulsive electric interactions that spatially orient their migration.
Models on segregation
Several computational models exist that attempt to explain and reproduce the experimentally observed segregation processes in various systems. While experimental works tend to focus on the role of tissue surface tension and adhesion in 3-dimensional cell segregation, modeling approaches also include autonomous cell motion and focus on 2 dimensions. A widely accepted model based on the Potts model and the idea of differential cell adhesion was developed by J Glazier and co-workers, later termed as Glazier-Graner-Hogeweg model or Cellular Potts Model (Graner & Glazier 1992). Variants of this model have been successfully employed in simulation works.
Impact of motility on segregation
Using Brownian dynamics simulations McCandlish et al. (2011) studied dense mixtures of self-propelled and passive rod-like particles in 2-dimensions where only excluded volume interactions can occur. Adhesion properties do not play a role here, particles only differ in motility. Spontaneous segregation of the two particle species generates a rich array of dynamical domain structures with properties depending on particle shape and propulsion velocity or the combination of these two in the form of particles’ Péclet number, a measure similar to the directional persistence of real cells.
Recently, Nakajima et al. (2011) used Cellular Potts Model (CPM) to study the dynamics of the segregation of mixtures of non-self-propelled cell types with diffusive motion. They have found that the increase in the size of segregated domains follows power law and the growth exponent is n = 1/3 for mixtures with 1:1 initial ratio of cell types where segregation proceeds via smoothing of the domain boundary. This is in contrast with previous works with CPM on smaller simulated systems displaying slower logarithmic growth for domain size (Graner & Glazier 1992; Mombach et al. 1995). CPM simulations with self-propelled cell types characterized by identical adhesive interactions as for the simulations in (Nakajima & Ishihara 2011) also yield domain growth exponent n = 1/3 (A. Czirók, personal communication).
Impact of adhesion on segregation
Qualitative description of the dynamical features and the geometry of cell segregation depending on intercellular adhesion parameters is provided by Voss-Böhme et al. (2010) using a stochastic interacting particle model. In this model the hierarchy of segregation is determined by the strengths of adhesive interactions between cells and the boundary.
In a unique paper combining experimental data and modeling Krieg et al. (2008) studied the role of cell-cortex tension and adhesion in segregation. Carrying out simulations using Cellular Potts Model with cell adhesion and cell-cortex tension data derived from experiments they could reproduce the experimentally observed final configurations of segregating germ line progenitor cell types.
Segregation by collective motion and adhesion
Taking a different approach Honda et al. (2008) studied pattern formation and emergence of asymmetry in mammalian blastocyst formation by simulations using a 3D vertex dynamics model. Endowing the simulated cells with equivalent mechanical properties and assuming that due to basement membrane formation the cell-medium surface in the forming blastocyst cavity is stiffer than cell-cell surfaces, the simulation successfully produced blastocyst structure with variable axis. Enclosing the simulated aggregate in an ellipsoidal capsule corresponding to the zona pellucida, the structure surrounding the blastocyst in vivo, eventually oriented the axis. Authors have shown the autonomous emergence of asymmetry as well as the formation and segregation of distinct cell populations of different sizes in an initially equivalent cell population without pre-existing intrinsic differences.
Our understanding of the events during embryonic development such as multicellular segregation and pattern formation is gradually shifting from a descriptive view towards a causative understanding of the mechanisms. Integrative biological attempts to promote this understanding have been successfully employing various approaches ranging from experimental embryology to statistical physics. Combination of experimental data with multi-disciplinary approaches including computational modeling and statistical physics can help us design more focused experimental tests or predict yet unseen outcomes and these can even further extend our understanding of the dynamic organization of multicellular biological systems.
TV is a statistical physicist and he is the principal investigator of the EU ERC COLLMOT project on collective motion. EM is a cell biologist specialized in cell motion research and he is a research fellow in the EU ERC COLLMOT project.
Differential adhesion hypothesis
Differential interfacial tension hypothesis
Tissue surface tension
Cellular potts model
Primary goldfish keratocytes
We thank Enys Mones (Dept. Biological Physics, Eötvös University) and András Czirók (Dept. Biological Physics, Eötvös University) for useful consultations. This work was funded by the European Union ERC COLLMOT Project.
